Product Description
34 Gallon Marine & RV Tank | Holding & Fresh Water | Trionic WH-2034
The 34 Gallon Trionic Marine & RV Tank, Holding & Fresh Water, WH-2034 is designed for boats, RVs, and other mobile applications where a durable, space-efficient tank is required. This rectangular polyethylene tank supports potable and fresh water storage as well as wastewater holding, including grey and black water, in non-pressurized setups. With a footprint of 23" length × 20" width × 17" height, the WH-2034 balances practical capacity with flexible placement.
This listing supports two configurations: Pre-drilled Tank and Blank Tank. The pre-drilled option includes two 1-1/2" FPT and two 1/2" FPT female NPT threaded openings located on one end. Unused openings can be capped. The blank option is supplied without factory openings, allowing custom fitting placement. Trionic’s CF-60 Custom Fittings Kit is the compatible accessory for blank-tank applications and custom routing.
The tank is rotationally molded as a seamless, one-piece unit with an approximate 3/8" average wall thickness. For installation, the bottom should be fully supported. Trionic also recommends using a 12" minimum length of flexible hose to hose barb fittings.
FEATURES
-
Product Type: Marine & RV Tank, Holding & Fresh Water
-
Model: Trionic WH-2034
-
Capacity: 34 Gallon
-
Tank Shape: Rectangular
-
Usability: Portable
-
Environment: Above Ground
-
Pressurized Use: No
-
Dimensions: 23" Length × 20" Width × 17" Height
-
Material / Color: Linear Low-Density Polyethylene (LLDPE), Natural White
Specifications
KEY SPECIFICATIONS
- Product Type: Marine & RV Tank (Holding & Fresh Water)
- Model: Trionic WH-2034 (pre-drilled) / B-2034 (blank)
- Capacity: 34 Gallon
- Tank Shape: Rectangular
- Usability: Portable
- Environment: Above Ground
- Pressurized Use: No
- Dimensions: 23" Length × 20" Width × 17" Height
- Material: Linear Low-Density Polyethylene (LLDPE)
- Color: Natural White
- Wall Thickness: 3/8" average
- Fittings: Pre-Drilled: (2) 1-1/2" FPT and (2) 1/2" FPT female NPT threaded openings on one end; Blank: no openings
- Compatible Accessory: DIY CF-60 Custom Fittings Kit (for blank tanks)
- Uses: Potable and fresh water storage; grey and black water holding
- Warranty: 1-year (materials and workmanship)
COMPLIANCE REFERENCES
- FDA – 21 CFR § 177.1520 – Trionic states each tank fully complies
- U.S. Coast Guard – Trionic states its tanks meet all U.S. Coast Guard regulations
SHIPPING INFORMATION
- Freight Class: 125
- Liftgate Option: Yes
- Locations: Wisconsin
- Zip Codes: 53021
Custom and Made to Order products are not returnable
