Images may be inaccurate. See specs below to ensure accuracy.
Product Description
The 5000 gallon Peabody ProChem Double Wall Tank Value-Pak pairs a double-wall containment tank with its lid, fittings and accessory package under one part number. Silver, Gold and Platinum levels are offered, and the level decides how much of the system ships with the tank.
Measuring 119" diameter x 152" high, this ProChem Double Wall Tank Value-Pak holds 5000 gallons and opens through a 16 in lid.
MATERIAL OPTIONS
- Silver — Part No.: 293-29177
- Gold — Part No.: 293-29191
- Platinum — Part No.: 293-29205
FEATURES
- Double-wall tank-in-a-tank containment supplied as a packaged system
- Built to meet EPA 40 CFR secondary containment requirements
- Lid and fitting sizes are listed per model
- Silver, Gold and Platinum package levels; ask us for the bill of materials
MATERIAL SELECTION GUIDANCE
Linear polyethylene (LPE) is typically selected for general chemical and water storage; cross-linked polyethylene (XLPE) where greater impact and stress-crack resistance is preferred; polypropylene (PPL) and polyvinylidene fluoride (PVDF) for resin-specific chemistries. Choose based on chemical compatibility first: suitability depends on your specific chemical, its concentration and its temperature, and is the buyer's responsibility to verify before ordering. The specific gravity rating states the heaviest liquid the wall is designed to hold — a 1.5 wall up to about 12.5 lb per gallon, a 1.9 wall up to about 16 lb per gallon.
These are vented, atmospheric storage tanks. Not for pressurized or vacuum service.
CHEMICAL COMPATIBILITY RESOURCES
- Peabody Chemical Resistance Chart (PDF)
- Polyethylene Chemical Resistance Chart (PDF)
- Polypropylene Chemical Resistance Chart (PDF)
- Chemical Compatibility Tool
Compatibility data is published by resin and chemical suppliers as general guidance only. Contact us with your chemical, concentration and temperature before you order.
Specifications
KEY SPECIFICATIONS
- Product Type: ProChem Double Wall Tank Value-Pak
- Tank Shape: Cylindrical
- Pressurized Use: No
- Capacity: 5000 Gallons
- Dimensions: 119" diameter x 152" high
- Manufacturer: Peabody Engineering
- Manufacturer Part Number: 293-29177 / 293-29191 / 293-29205
SHIPPING INFORMATION
- Freight Class: 250
- Locations: Liberty, South Carolina
- Zip Codes: 29657
WARRANTY TERMS
Peabody Engineering warrants this product against defects in material and workmanship for 36 months from the date of shipment, when it is installed, used and maintained as intended. Chemical compatibility, service temperature and liquid specific gravity are the buyer's responsibility: damage from an incompatible chemical, from service above the rated temperature, or from a liquid heavier than the wall rating is not covered.
Custom and Made to Order products are not returnable
